Provide 2,000 watts of 60 Hz power to cabin and galley accessories with the TI2000 inverter from True Blue Power. This inverter is capable of operating in a three-phase configuration by using three units interconnected, producing 6,000 watts of power. The unit is FAA TSO certified and offers a two-year limited warranty.
- Supplies 2,000 watts of wall outlet power
- Ideal for emergency medical equipment, special mission and VIP cabin configurations
- Lightweight — 7.7 lbs
- 93% efficiency
- Input transient, overload and short-circuit protection — up to 150% of rated load without damage
- Remote On/Off optional
- FAA TSO-C73 certified
- EASA ETSO-C73 certified
- RTCA DO-160G qualified
- Designed and built in Wichita, Kansas, USA
- Two-year limited warranty
- Input Voltage: 20 – 36 VDC
- Input Current: 80 A at 28 VDC input
- Output Voltage: 115 VAC ± 3%
- Output Power: 2,000 VA
- Output Frequency: 60 Hz ± 0.1%
- Output Waveform: Single phase, true sine wave, less than 3% total harmonic distortion
- Weight: 7.7 lbs (3.49 kg)
- Altitude: 55,000 ft
- Humidity: Tested to greater than 95% for 10 days, temperature cycle of 75°F to 160°F
- Temperature: -67°F to +158°F (-55°C to +70°C)
- Integral Cooling: Dual, electronically-controlled brushless fans
- Mating Connector: P/N 9018784-1, P/N 9018550-2 (cable clamp / backshell)
- Case: Anodized aluminum extrusion, blue
- Certification: FAA TSO-C73 certified, EASA ETSO-C73 certified, RTCA DO-160G qualified
